Nokia 3100 Service Manual

nokia
CONNECTING PEOPLE
PAGE 5 (22) Approved 1.0
Nokia Mobile Phones Customer Care EMEA
DJk
Technical Services, Repair Concepts Confidential 22.08.2003
3. PATHFINDER FOR WORKSHOP STAFF
In addition to the information in this Service Manual, there are several instructions and information, which
have to be followed.
Main documentation database is Nokia Partner Website
, which refers also to Nokia Care Point with the
purpose of serving different multimedia content, like video clips or interactive tutorials.
Nokia Partner Web Site Nokia Care Point
It is mandatory to watch for newest technical and organizational information on a daily basis to be
updated as required (see “Latest Updates in support Library”). Every new information has to be processed
and implemented as soon as possible.
When logged into PWS you can also find needed information to different headlines respectively tools
like:
Downloads
Support Library
Accessories
Battery Tester
Common Software
Flashing Tools
General --> Instructions
GoNoGo Tester
Service Tools
Tester Support
Wintesla
Products (Service Manuals, Service Bulletins)
To spare server bandwidth it is recommended to download newest version of huge files like videos,
Phoenix packages or Service Manuals only once and distribute it internally for further use.
Service Manual 3100 Level 1&2 Copyright 2003 © Nokia Corporation

Nokia 3100 Specifications

General

FM radio	No
Ringer type	Polyphonic
Interface	Pop-Port, DKU-5
Bundled software	Nokia PC Suite (aviliable separetly)
Operating frequency	EGSM 900, GSM 1800, GSM 1900 MHz
Internal memory	0.484 MB
Product color	White
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	BL-5C
Battery capacity	850 mAh
Display type	-
Display resolution	128 x 128 pixels
Display number of colors	4096 colors
WAP	1.2.1
Data network	GPRS

Weight and Dimensions

Weight	85 g
