Nokia 3100 Service Manual

nokia
CONNECTING PEOPLE
PAGE 7 (22) Approved 1.0
Nokia Mobile Phones Customer Care EMEA
DJk
Technical Services, Repair Concepts Confidential 22.08.2003
5. SPARE PARTS LIST
SPARE PARTS
ITEM/
CIRCUIT REF.
QTY
PART NO
PART NAME
I001 1 XXXXXXX A-COVER
I002 1 XXXXXXX KEYPAD
I003 6 6290119
SCREW 1.8X6 RF T6+ BLK
I004 1 - SYS MODULE MX5
I005 1 - Shielding Assembly
I008 1 9453311
POWER BUTTON
I010 1 9453273
B-COVER
I013 1 XXXXXXX C-COVER
I014 1 5400243
CONN DC-JACK 3.5MM 3POL SPR 90DEG
I015 1 5140265
MIC MOD+HOLDER TOMAHAWK -42+-3DB
I016 1 6800069
MATSUSHITA VANESSA VIBRA 1.3V
I017 1 9560199
SIM-FLAP
I018 1 9510935
C-COVER REL. SPR. DMD08481
I019 1 9453272
C-COVER REL. BUT. DMD10535
1 9498010 UI-MODULE ASSY (I020 – I024)
1 9491669 UI-SHIELD KEY DOME ASSY (I020 – I021)
I021 1 - KEY DOME
I020 1 - UI-SHIELD
I022 1 5140251
EARPIECE105+-3DB32R D8.1X2.25 PICO
I023 1 - LCD MODULE
I024 2 9560206
LOCKING CLIP
1 0660266 ANTENNA ASSY (I030 – I034)
I030 1 - IHF LID
I031 2 - IHF PIN
I032 1 - SPEAKER HF 69+-2DB 8R D16X4.36
I033 1 - IHF ENCLOSURE
I034 1 - ANTENNA RADIATOR
I035 1 - TYPE LABEL
Service Manual 3100 Level 1&2 Copyright 2003 © Nokia Corporation

Nokia 3100 Specifications

General

FM radio	No
Ringer type	Polyphonic
Interface	Pop-Port, DKU-5
Bundled software	Nokia PC Suite (aviliable separetly)
Operating frequency	EGSM 900, GSM 1800, GSM 1900 MHz
Internal memory	0.484 MB
Product color	White
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	BL-5C
Battery capacity	850 mAh
Display type	-
Display resolution	128 x 128 pixels
Display number of colors	4096 colors
WAP	1.2.1
Data network	GPRS

Weight and Dimensions

Weight	85 g
