Nokia 3100 Service Manual

nokia
CONNECTING PEOPLE
PAGE 8 (22) Approved 1.0
Nokia Mobile Phones Customer Care EMEA
DJk
Technical Services, Repair Concepts Confidential 22.08.2003
SOLDERING COMPONENTS ONLY FOR LEVEL 2
ITEM/
CIRCUIT REF.
QTY
PART NO
PART NAME
V310 1 4864577
LED SML512WBC2WT86N 0603
V311 1 4864577
LED SML512WBC2WT86N 0603
V318 1 4864577
LED SML512WBC2WT86N 0603
V319 1 4864577
LED SML512WBC2WT86N 0603
V322 1 4864577
LED SML512WBC2WT86N 0603
V323 1 4864577
LED SML512WBC2WT86N 0603
F100 1 5119019
SM FUSE F 1.5A 32V
S302 1 5200025
SM TACT SW SIDE TRAVEL 0.2 MM
VARIANT PARTS
ITEM/
CIRCUIT REF.
QTY
PART NO
PART NAME
I001 1 9459929
A-COVER WHITE
I001 1 9459926
A-COVER RED
I001 1 9459928
A-COVER LIGHT BLUE
I001 1 9459930
A-COVER BLACK BLUE
I002 1 9791085
KEYPAD LATIN
I002 1 9791086
KEYPAD CYRILLIC
I002 1 9791077
KEYPAD GREEK
I002 1 9791081
KEYPAD HEBREW
I002 1 9791079
KEYPAD ARABIC
I013 1 9453356
C-COVER BLACK BLUE DMD10532
I013 1 9453355
C-COVER RED DMD10532
I013 1 9453353
C-COVER LIGHT BLUE DMD10532
I013 1 9453352
C-COVER WHITE DMD10532
Service Manual 3100 Level 1&2 Copyright 2003 © Nokia Corporation

Nokia 3100 Specifications

General

FM radio	No
Ringer type	Polyphonic
Interface	Pop-Port, DKU-5
Bundled software	Nokia PC Suite (aviliable separetly)
Operating frequency	EGSM 900, GSM 1800, GSM 1900 MHz
Internal memory	0.484 MB
Product color	White
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Battery type	BL-5C
Battery capacity	850 mAh
Display type	-
Display resolution	128 x 128 pixels
Display number of colors	4096 colors
WAP	1.2.1
Data network	GPRS

Weight and Dimensions

Weight	85 g
