E-240G-B unit data sheet
52
7368 ISAM ONT E-240G-B Product Guide
3FE-46261-AAAA-TCZZA Issue: 01
5.8 E-240G-B detailed specifications
Table 9 lists the physical specifications for E-240G-B ONUs.
Table 9 E-240G-B ONU physical specifications
Table 10 lists power consumption specifications for E-240G-B ONUs.
BTRY Off
Green
Battery alarm set or battery not provisioned
(not affected by AC power failure)
Battery charged; no battery alarms
FAIL Off
Red
ONU is operating without failure
ONU operation failure (not ranged)
DATA 1 to 4 Off
Green
Not provisioned or no Ethernet connection
Link detected/operational
NTWK Off
Green solid
1490 nm data path is not available
1490 nm data path is available/operational
MGMT Green solid
Green flashing
Off
Full communication, ranging, sync between OLT/ONU
Software download
ONU is offline
POTS Off
Green solid
No POTS provisioned (all phones are on-hook or no phones connected)
One or more phones is off-hook
Indicator LED color and
behavior
LED behavior description
(2 of 2)
Dimensions Specifications
Length 8.2 in. (20.8 cm)
Width 5.6 in. (14.2 cm)
Height without fiber tray 1.3 in. (3.3 cm)
Height with fiber tray 1.9 in. (4.9 cm)
E-240G-B ONU when installed inside an outdoor enclosure
Height 13.5 in. (34.3 cm)
Width 12 in. (30.5 cm)
Depth 4.3 in. (10.9 cm)
E-240G-B ONU
Weight without fiber tray [within ± 0.5 lb (0.23
kg)]
0.57 lb (0.26 kg)
Weight with fiber tray [within ± 0.5 lb (0.23 kg)] 0.71 lb (0.32 kg)
Release 06.01.01 | June 2019 | Edition 09
