RADIUS Attributes Reference
246
RADIUS ATTRIBUTES REFERENCE GUIDE
RELEASE 14.0.R4
3HE 10793 AAAB TQZZA 01 Issue: 01
68 Acct-Tunnel-
Connection
string [4|8] bytes Default format:
tunnel-start/stop : 8 Byte value representing
the lac + lns tunnel-id converted in
hexadecimallink-start/stop: maps to the AVP
15 call Serial Number from ICRQ (32 bit)
Configured format:
(if the resulting string is longer than 253
characters, it is truncated)
acct-tunnel-connection-fmt ascii-spec
<ascii-spec> : <char-specification> <ascii-
spec>
<char-specification> : <ascii-char>|<char-
origin>
<ascii-char> : a printable ASCII character
<char-origin> : %<origin>
<origin> : n | s | S | t | T | c | C
n - Call Serial Number
s | S - Local (s) or Remote (S) Session Id
t | T - Local (t) or Remote (T) Tunnel Id
c | C - Local (c) or Remote (C) Connection Id
82 Tunnel-
Assignment-ID
string 32 chars Example: Tunnel-Assignment-ID = Tunnel-1
86 Acct-Tunnel-
Packets-Lost
integer 4 Bytes Sum of all dropped packets on ingress and
egress Example:Acct-Tunnel-Packets-Lost =
748
87 NAS-Port-Id string no limits LAC: <prefix><space><slot/mda/
port:vlan|vpi.vlan|vci><space> <suffix> -
prefix: configurable string 8 chars max - suffix:
remote-id (max 64 chars) | circuit-id (max 64
chars) LNS: pre-defined format - LNS rtr-2#lip-
3.3.3.3#rip-1.1.1.1#ltid-11381#rtid-1285#lsid-
30067#rsid-19151#347
90 Tunnel-Client-
Auth-ID
string 64 chars. Example: Tunnel-Client-Auth-Id:0 = LAC-
Antwerp-1
91 Tunnel-Server-
Auth-ID
string 64 chars. Example: Tunnel-Server-Auth-ID:0 = LNS-
Antwerp-1
95 NAS-IPv6-
Address
ipv6addr 16 Bytes # ipv6-address
Example: NAS-IPv6-Address = 2001:db8::1
Table 73 L2TP Tunnel Accounting (Limits) (Continued)
Attribute ID Attribute Name Type Limits SR OS Format
