8260 User Guide version v. 0.06 [ 5 ] 4/21/00
Prepare your phone for use
3. Prepare your phone
for use
• Install the battery
First, remove the back cover
To attach and remove the battery, you need to
first remove the phone’s back cover.
1 Press down on the tab on the bottom of
the cover.
1 Slide the cover down and lift it off.
Next, insert the battery
Before you can use your phone, you must insert the battery.
2 Place the top of the battery on the phone, with the gold contacts
toward the top of the phone.
3 Press down on the bottom of the battery until it is fully down.
Last, replace the back cover
1 Place the cover on top of the battery so that none of the battery is
showing.
2 Slide the cover up until it clicks into place.
