Nokia A032 User Manual

SNMP manager
123
A032 LAN table (Ethernet)
Note that counters are 32 bit and overflow back
to 0.
A032 serial table
These entries pertain to the serial port on the
back of the A032 unit.
A032 distribution
This section relates to the Access Point function
of the A032.
LAN Interface Index Fixed value of 1.
LAN Status Indicates up or down (if disabled by management
process).
LAN Current Interface Indicates 10baseT.
LAN Rx All Frames Counter of all frames received by LAN interface.
LAN Rx Accept frames Counter of frames which are copied into Access Point for
processing.
LAN Rx Copied Octets Counter of bytes transferred into Access Point from LAN
interface.
LAN Rx Frame Discards Frames discarded by Access Point due to unspecified
problem.
LAN Tx All Frame Counter of all frames sent to LAN interface.
LAN Rx Sent Octets Counter of Bytes transferred to LAN interface.
Serial Status Indicates up or down depending on the state of DTR.
Number Associations How many wireless stations are currently associated
with the Access Point.
Number of LAN entries How many MAC addresses have been detected on the
LAN interface.
A032-Adv.book Page 123 Monday, November 13, 2000 10:47 AM
