Using the Web manager
29
Summary fields
The Summary fields are as follows:
DHCP log
The DHCP log records when stations request an
address and also when an address is leased.
Since the lease is renewed every hour this will
be the most common message. Note that new
entries in the log are placed at the top of the
list. This avoids the need to scroll down the list
to get the most recent information.
Detailed DHCP address information
The lower section of this screen allows a
manager to get specific information for an
address. To obtain the information:
1 Enter the IP address in the lefthand field.
2 Click
Enquire. The system will display the
lease status, lease duration and the MAC
address of the station to which the lease has
been granted.
3 To view the next IP address in the pool,
click
Next.
The lease status may be Open (unassigned)
Pending or Leased. If the status shows
“****”
the selected address is outside the DHCP
address pool.
Field Description
IP Base Address The DHCP base address as configured by the manager
Pool Size The DHCP pool size as configured by the manager
Free Addresses The number of unassigned addresses
Leased The number of addresses currently assigned and in use
Pending The number of addresses reserved due to pending
requests
