Using the Web manager
41
TCP/IP-related settings
For basic operation as an access point the
Nokia A032 does not need to be assigned TCP/
IP information. The default state of the unit is
to have no IP address assigned. However, in
order for you to be able to use most of the
management utilities and the Internet access
functions the access point needs an IP address
(which you can assign manually, or
automatically using the DHCP function).
The options associated with the TCP/IP
information are:
Note: If you modify
the IP address settings,
you may need to
renew the IP
information in your
wireless station – see
page 175.
Option Description
(Mgmt) IP address The IP address assigned to the Nokia A032 for
management purposes. Normally the network system
administrator will select this value.
If you do not want to assign an IP address, or if you want
to configure the Nokia A032 to assign itself an IP
address using its own DHCP server, set this field to
0.0.0.0
Changes to this field do not take effect until the unit is
restarted so that it is possible to change the IP value
without interfering with operation of the web browser.
IP Subnet Mask This must be set to the value used on the local IP
subnetwork to which the unit is attached
IP Gateway This is the address of the gateway router on the local
network. It is required if the access point management
functions will be accessed from outside the local sub-
network. Note that when Internet access is enabled, the
access point also acts as the gateway for the local LAN
segment; in that case the gateway value is assigned
automatically and cannot be overridden.
A032-Adv.book Page 41 Monday, November 13, 2000 10:47 AM
