Table 15 Receiver characteristics
Item Values
Type Direct conversion, Linear, FDMA/TDMA
LO frequencies GSM850: 3476..3576 MHz (4 x RX freq)
EGSM900: 3700...3840 MHz (4 x RX freq)
GSM1800: 3610...3760 MHz (2 x RX freq)
GSM1900: 3860...3980 MHz (2 x RX freq)
Typical 3 dB bandwidth +/- 91 kHz
Sensitivity min. - 102 dBm (normal condition)
Total typical receiver voltage gain (from
antenna to RX ADC)
86 dB
Receiver output level (RF level -95 dBm) 40 mVpp, single-ended I/Q signals to RX ADCs
RM-272; RM-273
System module
Issue 1 COMPANY CONFIDENTIAL Page 5 –19
