SS-116 adaptor frame
SS-116 Adaptor frame is used with MJ-122 Module Jig.
The Module Jig MJ-122 is delivered with an adaptor frame for use with
RM-217 and RM-222. The Guiding pins are in different positions for
RM-237/272/273/274. Each adaptor frame is marked according to the
transceiver type that it can be used with. Remove the existing adaptor
frame and replace with SS-116 to enable MJ-122 re-use with
RM-237/272/273/274 phone."
General tools
The table below gives a short overview of service tools that can be used for testing, error analysis and repair
of product RM-272; RM-273, refer to various concepts.
RM-272; RM-273
Service Tools and Service Concepts
