Nokia RM-824 - Page 140

Function Description Item ref
GPS RF connector GPS with combined Band 7 diversity antenna X7801
Battery BP-5T
Battery connector Tabby blade interface X2002
Display connector Board-to-board connector X1350
Touch connector Board-to-board-connector X1351
eMMC 8GB internal mass memory D3200
USB connector Micro USB-AB X3300
Micro SIM connector Micro SIM connector X2700
Audio IC WCD9310 N2190
AV connector Standard 3.5 mm, dynamic switching for AHJ and NHJ X2160
Earpiece Lean B2130
Microphone 2 x Tufnel B2132
B2133
IHF Amazon B2135
Vibra SisuX M2110
Accelerometer 3-axis accelerometer Ahti2 N1140
Magnetometer 3-axis magnetic sensor N1110
Combined Proximity
Sensor and Ambient Light
Sensor
Alphamon N1101
Gyroscope 3-axis sensor N1120
Camera socket SMIA85++ AF camera X1400
RM-824; RM-825; RM-826
System Module
