Nokia RM-824 - WCDMA VIII (900) Frequencies; LTE B1 Frequencies; LTE B3 Frequencies; LTE B7 Frequencies

Uplink CH (TX) TX Freq
(MHz)
TX VCO Freq
(MHz)
Downlink CH (RX) RX Freq
(MHz)
RX VCO Freq
(MHz)
4233 846.6 3386.4 4458 891.6 3566.4
WCDMA VIII (900) frequencies
Uplink CH (TX) TX Freq
(MHz)
TX VCO Freq
(MHz)
Downlink CH (RX) RX Freq
(MHz)
RX VCO Freq
(MHz)
2712 882.4 3529.6 2937 927.4 3709.6
2788 897.6 3590.4 3013 942.6 3770.4
2863 912.6 3650.4 3088 957.6 3830.4
LTE B1 frequencies
Uplink CH (TX) TX Freq
(MHz)
TX VCO Freq
(MHz)
Downlink CH (RX) RX Freq
(MHz)
RX VCO Freq
(MHz)
18000 1920.0 3840.0 0 2110.0 4220.0
18300 1950.0 3900.0 300 2140.0 4280.0
18599 1979.9 3959.8 599 2169.9 4339.8
LTE B3 frequencies
Uplink CH (TX) TX Freq
(MHz)
TX VCO Freq
(MHz)
Downlink CH (RX) RX Freq
(MHz)
RX VCO Freq
(MHz)
19200 1710.0 3420.0 1200 1805.0 3610.0
19575 1747.5 3495.0 1575 1842.5 3685.0
19949 1784.9 3569.8 1949 1879.9 3759.8
LTE B7 frequencies
Uplink CH (TX) TX Freq
(MHz)
TX VCO Freq
(MHz)
Downlink CH (RX) RX Freq
(MHz)
RX VCO Freq
(MHz)
20750 2500.0 5000.0 2750 2620.0 5240.0
21100 2535.0 5070.0 3100 2655.0 5310.0
21449 2569.9 5139.8 3449 2689.9 5379.8
LTE B8 frequencies
Uplink CH (TX) TX Freq
(MHz)
TX VCO Freq
(MHz)
Downlink CH (RX) RX Freq
(MHz)
RX VCO Freq
(MHz)
21450 880.0 3520.0 3450 925.0 3700.0
21625 897.5 3590.0 3625 942.5 3770.0
RM-824; RM-825; RM-826
System Module
Issue 2 NOKIA INTERNAL USE ONLY Page 6 – 29
Copyright © 2012 Nokia. All rights reserved.
