Nokia RM-824 - Service Tools and Service Concepts

Parameter Unit
Channel spacing GSM850: 200 kHz
GSM900: 200 kHz
GSM1800: 200 kHz
GSM1900: 200 kHz
WCDMA VIII (900): 200 kHz
WCDMA V (850): 100/200 kHz
WCDMA II (1900): 100/200 kHz
WCDMA I (2100): 200 kHz
LTE B4 (1700/2100): 100 kHz
LTE B17 (700): 100 kHz
Number of Tx power levels GSM850: 15
GSM900: 15
GSM1800: 16
GSM1900: 16
WCDMA VIII (900): 75
WCDMA V (850): 75
WCDMA II (1900): 75
WCDMA I (2100): 75
LTE B4 (1700/2100): 62
LTE B17 (700): 62
Service tools and service concepts
The table below gives a short overview of service devices that can be used for testing, error analysis, and
repair of product RM-824; RM-825; RM-826. For the correct use of the service devices, and the best effort of
workbench setup, please refer to various concepts.
RM-824; RM-825; RM-826
Service information differences between RM-824 and
RM-825
Issue 2 NOKIA INTERNAL USE ONLY Page 7 – 11
Copyright © 2012 Nokia. All rights reserved.
