ACCESS GATEWAY
308 Quick Reference Guide
REGULATORY
FCC Class A
UL, UL (US and Canada)
CE
EN 55022: 2010 Class A, EN 61000-3-2:2006/A1:2009/A2:2009, EN 61000-3-
3:2008, EN55024:2010 (IEC 61000-4-2:2008, IEC 61000-4-3:2006/A1:2007/
A2:2010, IEC 6100-4-4:2004/A1:2010, IEC 6100-4-5:2006, IEC 61000-4-6:2008,
IEC 61000-4-8:2009, IEC 6100-4-11:2004),
Australian Standard AZ/NZS CISPR 22:2009 Class A CB Scheme
P
HYSICAL
1U rack space in a 19” rack
17”(L) x 12”(W) x 1.75”(H)
431mm (L) x 305.0mm (W) x 44.4mm (H)
Weight: 10.2 lbs.
Weight: 4.6 Kg
LED I
NDICATORS
Power Indicator
Status Indicator
ACT/LINK and 10/100/1000 for each Ethernet port
P
ERFORMANCE
User Support: Up to 4000 users or devices concurrently
Throughput: up to 970Mbits/s*
*As defined by RFC1242, Section 3.18
AG5800 Specifications
