33
Figure 44 - John Deere Boom Valve Block (top view) with Connectors Labeled
Some older model John Deere sprayers (4700 and 4710) may have a different style boom
valve block that has different connector arrangements. The NORAC interface cable (C12)
44658-01 will require modification. See Appendix A for modification procedure.
Rear of
Sprayer
Front of
Sprayer
