3 PARTS LISTS
The parts that come with your UC4+ Spray Height Control System are listed in Table 1. The item
number on the left side of this table references each part.
Please ensure that all parts in your kit are present before proceeding with your installation.
Table 1 – John Deere 4720 Active Roll Sprayer Boom Control System Parts
Item Part Number Name Quantity
B05 44706-01 KIT CABLE TIE BLACK 10 PCS 21 IN 150 PCS 7.5 IN 1
B09 44695-10 BRACKET SPRAYER FRAME TARGET ROLL BIAS CYLINDER REV C 1
B11 44740 MOUNTING BRACKET ROLL SENSOR UC4 1
B12 44741 MOUNTING BRACKET ROLL SENSOR TARGET UC4 1
B13 44728 MOUNTING BRACKET COMPLETE UC4 BREAKAWAY EXTENDED 2
B14 44674 MOUNTING BRACKET MAIN LIFT SENSOR UC4 PLUS 1
B16 105415 CLAMP EXHAUST 2IN PLATED 4
B18 44695-18 PIN ACTIVE ROLL CYLINDER UPPER JD 20MM ZINC 1
C01 44662B-40 CABLE UC3 SENSOR TRUNK AMPF TO AMPF BLACK STANDARD 40FEET 1
C02 44668 CABLE UC3 SENSOR BRANCH 1 AMP RECEPT 3 AMP PLUG BC 1
C03 44656D CABLE VALVE VARIABLE RATE DT 1
C04 44651 CABLE VALVE EXTENSION 1
C10 44650-14 CABLE POWER UC3 BOOM CONTROL JOHN DEERE 1
C12 44658-01 UC3 CABLE VALVE BC JD REV-A 1
C70 44658-08D CABLE VALVE ROLL BIAS DT 1
C71 44674 CABLE UC3 SENSOR ROLL BIAS 2
E01 4461BC+ UC4 PLUS BOOM CONTROL PANEL 1
E02 44631 UC4 ULTRASOUND SENSOR 4
E03 45000* UC4 PLUS ROLL SENSOR W TEMPERATURE PROBE VER. 2 1
H02 44863-23 HOSE ASSEMBLY 122R2-06 32 IN L 6FORX 6FORX 2
H06 44862-05 HOSE ASSEMBLY 122R2-04 144 IN L 4FORX 4FORX 1
H20 44865-19 HYDRAULICS FITTING KIT - JD7 1
H21 44865-38 HYDRAULICS FITTING KIT - ACTIVE ROLL 1
H70 44864-04 HOSE ASSEMBLY 122R2-08 168 IN L 6FORX 12FORX 1
H71 44864-03 HOSE ASSEMBLY 122R2-08 166 IN L 6FORX 6FORX 1
