Page7
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
3.3.2. HydraulicFittingKitDetails(P/N:44865‐48)
Thefollowingfittingsareusedforconnectingthemainlifthydraulics.
Item PartNumber Name Quantity Picture
*F03 104586 TEEADAPTER‐6FORXR6MORT 2

*F04 44917 MALEADAPTER‐6MB6MOR 2




3.3.3. HydraulicFittingKitDetails(P/N:44865‐75)
Thefollowingfittingsareusedforconnectingtheactivewingrollhydraulics.
Item PartNumber Name Quantity Picture
F12 44917 MALEADAPTER‐6MB6MOR 6

F13 104586 TEEADAPTER‐6FORXR6MORT 4

F14 104590 90DEGADAPTER‐6MOR6FORX90 9




Notallfittingsareusedforthisinstallation.

Donotusehighspeedpowertools/drillswheninstallinghardware.

TheuseofdielectricgreaseisnotrecommendedonanyNORACelectricalconnections.

Toensure allstainlesssteelhardwaredoesnotgall orseizeapply alight coatingof thesuppliedPermatex
Anti‐seize grease to all threaded parts upon installation. Permatex Anti‐seize lubricant is preferred, but
othersimilaranti‐seizeproductsmaybeused.
