Page6
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
3.3.1. HydraulicFittingKitDetails(P/N:44865‐06)
Item PartNumber Name Quantity Picture
F02 103312 MALEADAPTER‐6MB6MJ 2

F03 104586 TEEADAPTER‐6FORXR6MORT 4

F04 104886 MALEADAPTER‐8MOR8MB 2

F05 44917 MALEADAPTER‐6MB‐6MOR 8

F06 104885 TEEADAPTER‐8FORXR8MORT 2

F07 104590 90DEGADAPTER‐6MOR6FORX90 4

F08 104369 PLUG‐6MBP 2

F09 44928 ONEWAYORIFICEINSERT‐0.047 4

F10 104592 O‐RINGHYD3.8INFLATFACE 2

F11 105184 ORIFICEINLINE6FLATFACE 2




Notallfittingsareusedforthisinstallation.

 
6 M B - 6 M OR X 90
SIZE IN
1/16
TH'S
GENDER: MALE
OR FEMALE
90
° ANGLE
SWIVEL
TYPE
GENDER
SIZE
TYPE:
B - ORB
J - JIC
OR - FLAT
FACE
P - PIPE
Fitting Name
Example:
