5  HydraulicInstallation

Ensure all pressure has been bled from the system before disconnecting any lines or fittings.Hydraulic
pressure will exist on the wing tilt circuits unless the wings are being supported by other means.The
hydraulicinstallationmaybeperformedwiththewingsintransportposition,restingonthegroundorwith
thetiltcylindersfullyextended.

Component failure due to oil contamination is not covered under the NORAC system warranty. It is
recommendedthataqualifiedtechnicianperformthehydraulicinstallation.
5.1. ExpansionBlockAssembly
1. Removethefour4MBPplugsfromthe3stationvalveblock(Figure4).
2. Coat the four o‐rings in hydraulic oil and install them into the expansion  block.Ensure the o‐rings are
seatedproperly.
3. Attachtheexpansionblocktothe3stationblockusingtheincludedspringwashersandbolts. 
4. Tightentheboltsto31ft‐lbs(42Nm).

Figure4:NORACExpansionBlockAssembly
