7  ElectronicInstallation
7.1. HCM1Installation
1. Verify the valve coil connectors are oriented vertically (Figure 22).Loosening the large plastic nut will
allowtheconnectortoberotated.

Figure22:AlignCoils

Figure23:HCM1Connections

Figure24:HCM1Label
2. Laythelongerbranchofthevalvecables(C10)acrossthe coilswithtwo4‐pinconnectorsoneachside.
Donotconnectthecablesatthistime.
OutputNumber NormalFunction
1,2 LeftUpandDown
3,4 RightUpandDown
5,6 MainUpandDown
7,8 RollCWandCCW
