6.5. MainLiftSensorInstallation
1. Themainliftmountingbracket(B21)isthebracketwiththelongermountingflange.
2. Thereareavarietyofwaystomountthemainliftbracketonmostsprayers.Thebracketshouldposition
the sensor approximately in the center of the sprayer, forward of the boom.An example of
 this
mountingisillustratedinFigure21.
  
Figure20:BracketMountingExample
3. Mounttheultrasonicsensortothemainliftbracket.Runthesensorcablethrough theholeandbehind
thebracket.
 
Figure21:ExampleMountingoftheMainLiftBracket

Ensurethebracketdoesnotcollidewithanyotherpartofthesprayerthroughoutthefullrangeofmainlift
motion.
Front
