25. ConnecthoseH06betweenthe“B”portonthewingrollcylinder(H20)andthe“B”portontheNORAC
expansionblock.

ThisfollowingportionoftheinstallisonlyforCase120’booms.
26. Beforecontinuing,makesuretheboomsareloweredallthewaytothebottomofthecylindertravel.
27. Placeoneoftheo‐rings(F10)intotheo‐ringgrooveontheinlineorifice(F11).
28. Removethewingaccumulatorandinserttheinlineorifice(F11)betweentheaccumulatorandfitting.
29. Reassembleandrepeatfortheoppositetiltcylinder.

Figure9:TiltCylinderOrificeLocation

Startupthesprayerandtestthesprayer’sfunctionality.Unfoldtheboomsandraise/lowereachboomand
themainsection.Ensurethattherearenoleaks.


