Page17
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
6.3. RainflapInstallation

Rainflapsareonlyinstalledinthewingsensorbrackets.
1. Insertonesideoftherainflaprodintothepre‐benthingetabonthesensorbracket.(Figure12)

Figure12:RainflapRodinPre‐BentHingeTab
2. Aligntheothersideoftherainflaprodwiththeunbenthinge tab.(Figure 13) 

Figure13:AlignRainflapRod
3. Bendthehingetabinwardovertherainflaproduntilthehingetabfitssecurelyinthedetentgrooveon
thebacksideofthesensorbracket.(Figure14)

Figure14:BendRainflapHingeTab
4. Ensuretherainflapactuatessmoothlywhenthebracketisturnedupsidedownandreturnstotheopen
position when the sensor bracket is returned to its operating position (sensor pointing downwards
towardtheground).
