7.2. CablingConnections
1. Fasten the 8‐way coupler to the boom with cable  ties.Connect cable C02 between the 8‐way coupler
(E11)andthe6‐pinNORACbusconnectoronthe HCM1.

Figure29:NORACBusLocation
2. Connectthewingrollcylinder(H20)tothe8‐waycoupler.
3. Connectthemainliftsensortothe8‐waycouplerusingcableC01anda2‐waycoupler(E12).CableC01
anditemE12maynotbeneededifthe8‐waycouplerismountedcloseenoughtothemainliftsensor.
4. Insertthe6pinplugs(P03)intotheremainingreceptaclesofthe8‐waycoupler.
NORACBus
