1200 SERIES - PARTS LIST- Page 14
CABINET ASSEMBLY - FRONT VIEW - 1200 SERIES
NO. PART # DESCRIPTION
1200AC
SERIES
1200LR
SERIES
1201LR
SERIES
1 623255 TRIM PIECE-TOP/BOTTOM/"U" SHAPED (SERIAL# 1097521 & ABOVE) X X X
621975 TRIM PIECE-TOP/BOTTOM (SERIAL# 300000 TO 1097520) X X
3 618844 TRIM PIECE-CORNER (4 PER CABINET)(SERIAL# 300000 TO 1097520) X X
4 618798 HINGE-TOP RH/BOTTOM LH/PANEL DOOR (2 PER CABINET) PANEL PANEL PANEL
623824 HINGE-TOP RH/BOTTOM LH/WRAPPED DOORS (2 PER CABINET) WRAPPED WRAPPED WRAPPED
5 623254 TRIM PIECE-SIDE (2 PER CABINET)(SERIAL# 1097521 & ABOVE) X X X
621976 TRIM PIECE-SIDE (2 PER CABINET)(SERIAL# 300000 TO 1097520) X X
6 627685 HINGE-MIDDLE (2 PER CABINET) X X X
627684 HINGE PIN-MIDDLE HINGE X X X
7 628970 CONTROL ASSY-OPTICAL (SERIAL # 8981139 & ABOVE) X X
629042 CONTROL ASSY-OPTICAL (SERIAL # 9098172 & ABOVE) X
624868 CONTROL ASSY-OPTICAL/GRAY MONOCHROME (SERIAL # 832172 TO 8981138) LTD LTD LTD
624869 KIT-CONTROL ASSY/POWER BOARD/GRAY (SERIAL # 300000 TO 832171) LTD LTD
633205 KIT-CONTROLS ADAPTER (SERIAL# 300000 TO 520960) X X
633275 KIT-CONTROLS ADAPTER (SERIAL# 520961 TO 832171) X X
633299 KIT-CONTROLS ADAPTER (SERIAL# 832172 TO 8981138) X X
633276 KIT-CONTROLS ADAPTER/AC (SERIAL# 300000 TO 9098171) X
8 618835 STRIKE PLATE X X X
9 618774 DRIP TRAY-INSIDE X X X
NS 628462 KIT-DRIP TRAY EDGE X X X
10 624140 GUIDE BLOCK ASSY-BTM/BLACK/DOUBLE POLE (SERIAL # 1291391 & ABOVE) X X X
624141 GUIDE BLOCK ASSY-TOP/BLACK/DOUBLE POLE (SERIAL # 1291391 & ABOVE) X X X
620043 GUIDE BLOCK ASSY-BTM/WHITE/DOUBLE POLE (SERIAL # 540295 TO 1291390) X X
620041 GUIDE BLOCK ASSY-TOP/WHITE/DOUBLE POLE (SERIAL # 540295 TO 1291390) X X
620042 GUIDE BLOCK ASSY-BTM/WHITE/SINGLE POLE (SERIAL# 300000 TO 540294) X
620040 GUIDE BLOCK ASSY-TOP/WHITE/SINGLE POLE (SERIAL# 300000 TO 540294) X
11 618144 HINGE BUSHING-DOOR HINGE/BLACK (TOTAL OF 4 PER CABINET) X X X
12 622033 RETAINER-SHELF (SERIAL # 926685 & ABOVE)(2 PER CABINET) X X X
618181 RETAINER-SHELF (SERIAL # 300000 TO 926684)(2 PER CABINET) X X
13 618145 HINGE PIN-DOOR (4 PER REFRIGERATOR) PANEL PANEL PANEL
623899 HINGE PIN-UPPER/LOWER/WRAPPED DOORS WRAPPED WRAPPED WRAPPED
14 618878 BIN-BOTTLE/CRISPER (TOTAL OF 3 PER CABINET) X X X
15 618877 DIVIDER-BOTTLE CRISPER (1 PER CABINET) X X X
16 61409622 CLIP-SHELF X X X
17 618144 HINGE BUSHING-DOOR HINGE/BLACK (TOTAL OF 4 PER CABINET) X X X
18 632608 SUPPORT WALL-FOR CRISPER BIN X X X
19 618878 BIN-BOTTLE/CRISPER (TOTAL OF 3 PER CABINET) X X X
20 618757 CRISPER COVER-GLASS SHELF (TWO PER CABINET) X X X
21 618848 SHELF-WIRE/LONG (3 PER CABINET) X X X
22 618849 SHELF-WIRE/SHORT X X X
23 618847 SHELF-WIRE/FREEZER (2 PER CABINET) X X X
24 618796 HINGE-TOP LH/BOTTOM RH/PANEL DOORS (2 PER CABINET) PANEL PANEL PANEL
623823 HINGE-TOP LH/BOTTOM RH/WRAPPED DOORS (2 PER CABINET) WRAPPED WRAPPED WRAPPED
25 623918 SWITCH-DOOR LIGHT (2 PER CABINET) (SERIAL # 1204743 & ABOVE) X X X
618884 SWITCH-DOOR LIGHT (2 PER CABINET) (SERIAL # 300000 TO 1204742) X X
26 625210 STRIP-FREEZER-BLACK (SERIAL # 1291391 & ABOVE) X X X
NS 618803 BIN-ICE (NOT SHOWN)-ICE MAKER MODELS X X X
NS 61630422 ICE TRAYS (NOT SHOWN)(4 PER CABINET) - NON ICE MAKER MODELS X X
NS 620689 PROBE-CONTACT/LARGE (NOT SHOWN)
NS 618853 CAP-SCREW/WHITE (NOT SHOWN)(SERIAL# 300000 TO 1097520) X X
NS 618170 HOLE PLUG-FOR TOP TRIM PIECE (NOT SHOWN)(SERIAL# 1097521 & ABOVE) X X X
LTD = LIMITED QUANTITIES AVAILABLE IN INVENTORY (USE KIT-CONTROL ADAPTER IF UNAVAILABLE)
NOTE: IF THE CONTROL ASSY-OPTICAL HAS BEEN REPLACED WITH A KIT-CONTROL ADAPTOR, THE POWER BOARD MUST BE
REPLACED WITH A NEW KIT-CONTROL ADAPTER.
