Norcold 1200AC - Lower RH Door Assembly - Panel Doors; Door Liner Assembly - Lower RH; Door Handle Assembly - Lower RH; Lower RH Door Hardware

1200 SERIES - PARTS LIST- Page 4
DOOR ASSEMBLY - LOWER RH - 1200 SERIES (PANEL DOORS)
NO. PART # DESCRIPTION
1200AC
SERIES
1200LR
SERIES
1201LR
SERIES
1 627600 DOOR LINER ASSY-BLACK GASKET (SERIAL # 1291391 & ABOVE) X
627991 DOOR LINER ASSY-BLACK GASKET (SERIAL # 1291391 & ABOVE) X X
627992 DOOR LINER ASSY-WHITE GASKET (SERIAL # 540295 TO 1291390) X X
627993 DOOR LINER ASSY-LOWER/RH/GRAY GASKET (SERIAL # 300000 TO 540294) X
2 622316 DOOR HANDLE ASSY (SERIAL # 8254600 & ABOVE) X X
619573 DOOR HANDLE ASSY (SERIAL # 300000 TO 8254600) X X
621107 DOOR HANDLE ASSY (SERIAL # 300000 & ABOVE) X
3 619374 STORAGE LATCH-DOOR/BLACK/POINTED (SERIAL # 300000 TO 8254600) X X X
4 618746 HINGE BUSHING-MIDDLE X X X
5 623167 PANEL RETAINER-LOWER (1 PER DOOR) X X X
6 618792 HINGE-DOOR/UPPER/WITHOUT PIN (SERIAL # 300000 TO 8254600) X X X
627289 HINGE-DOOR/LOWER/WITH PIN (SERIAL # 8254600 & ABOVE) X X X
7 622831 BIN-DOOR SHELF (3 PER DOOR) X X X
NS 625129 KIT-DOOR SAG REPAIR (LOWER DOORS)) X X X
NS = NOT SHOWN
