Norcold 1200AC - Upper RH Door Assembly - Panel Doors; Door Liner Assembly - Upper RH; Door Handle Assembly - Upper RH; Upper RH Door Hardware

1200 SERIES - PARTS LIST- Page 2
DOOR ASSEMBLY - UPPER RH - 1200 SERIES (PANEL DOORS)
NO. PART # DESCRIPTION
1200AC
SERIES
1200LR
SERIES
1201LR
SERIES
1 627603 DOOR LINER ASSY-UPPER/RH/BLACK GASKET (SERIAL # 1291391 T& ABOVE) X X X
627970 DOOR LINER ASSY-UPPER/RH/WHITE GASKET (SERIAL # 540295 TO 1291390) X X
627971 DOOR LINER ASSY-UPPER/RH/GRAY GASKET (SERIAL # 300000 TO 540294) X
2 622315 DOOR HANDLE ASSY (SERIAL # 8254600 & ABOVE) X X
619574 DOOR HANDLE ASSY (SERIAL # 300000 TO 8254599) X X
621106 DOOR HANDLE ASSY (SERIAL # 300000 & ABOVE) X
3 619374 STORAGE LATCH-DOOR/BLACK/POINTED (SERIAL # 300000 TO 8254600) X X X
4 618746 HINGE BUSHING-MIDDLE X X X
5 623166 PANEL RETAINER-UPPER (1 PER DOOR) X X X
6 622831 BIN-DOOR SHELF (1 PER DOOR) X X X
7 618792 HINGE-DOOR X X X
