Norcold 1200AC - Lower LH Door Assembly - Panel Doors; Door Liner Assembly - Lower LH; Door Handle Assembly - Lower LH; Lower LH Door Hardware

1200 SERIES - PARTS LIST- Page 5
DOOR ASSEMBLY - LOWER LH - 1200 SERIES (PANEL DOORS)
NO. PART # DESCRIPTION
1200AC
SERIES
1200LR
SERIES
1201LR
SERIES
1 627598 DOOR LINER ASSY-BLACK GASKET/NO FLAPPER (SERIAL # 1291391 & ABOVE) X X X
627978 DOOR LINER ASSY-BLACK GASKET/WITH FLAPPER (SERIAL # 1291391 & ABOVE) X X X
627599 DOOR LINER ASSY-BLACK GASKET/NO FLAPPER/DISPENSER MODELS X X
627979 DOOR LINER ASSY-BLACK GASKET/WITH FLAPPER/DISPENSER MODELS X X
627965 DOOR LINER ASSY-WHITE GASKET/NO FLAPPER (SERIAL # 540295 TO 1291390) X X
627980 DOOR LINER ASSY-WHITE GASKET/WITH FLAPPER (SERIAL # 540295 TO 1291390) X X
627966 DOOR LINER ASSY-GRAY GASKET/NO FLAPPER (SERIAL # 300000 TO 540294) X
627981 DOOR LINER ASSY-GRAY GASKET/WITH FLAPPER (SERIAL # 300000 TO 540294) X
2 618746 HINGE BUSHING-MIDDLE X X X
3 622315 DOOR HANDLE ASSY (SERIAL # 8254600 & ABOVE) X X
619574 DOOR HANDLE ASSY (SERIAL # 300000 TO 8254599) X X
621106 DOOR HANDLE ASSY (SERIAL # 300000 & ABOVE) X
4 619374 STORAGE LATCH-DOOR/BLACK/POINTED (SERIAL # 300000 TO 8254600) X X X
5 623887 FLAPPER ASSY-DOUBLE POLE/BLACK (SERIAL # 1291391 & ABOVE) X X X
619845 FLAPPER ASSY-DOUBLE POLE/WHITE (SERIAL # 540295 TO 1291390)(USE 623887) X X
618787 FLAPPER ASSY-SINGLE POLE/WHITE (SERIAL # 300000 TO 540294) X
NS 622855 KIT-FLAPPER WIRE REPAIR X X X
6 618792 HINGE-DOOR/UPPER/WITHOUT PIN (SERIAL # 300000 TO 8254600) X X X
627288 HINGE-DOOR/LOWER/WITH PIN (SERIAL # 8254600 & ABOVE) X X X
7 622831 BIN-DOOR SHELF (3 PER DOOR) X X X
8 623167 PANEL RETAINER-LOWER (1 PER DOOR) X X X
NS 625129 KIT-DOOR SAG REPAIR (LOWER DOORS) X X X
NS = NOT SHOWN
