1200 SERIES - PARTS LIST- Page 3
DOOR ASSEMBLY - UPPER LH - 1200 SERIES (PANEL DOORS)
NO. PART # DESCRIPTION
1200AC
SERIES
1200LR
SERIES
1201LR
SERIES
1 627601 DOOR LINER ASSY-BLACK GASKET (SERIAL # 1291391 & ABOVE) X X X
627960 DOOR LINER ASSY-WHITE GASKET (SERIAL # 540295 TO 1291390) X X
627961 DOOR LINER ASSY-GRAY GASKET (SERIAL # 300000 TO 540294) X
627602 DOOR LINER ASSY-DISPENSER MODELS (SERIAL # 1319557 & ABOVE) X X
2 622316 DOOR HANDLE ASSY (SERIAL # 8254600 & ABOVE) X X
619573 DOOR HANDLE ASSY (SERIAL # 300000 TO 8254600) X X
621107 DOOR HANDLE ASSY (SERIAL # 300000 & ABOVE) X
3 619374 STORAGE LATCH-DOOR/BLACK/POINTED (SERIAL # 300000 TO 8254600) X X X
4 618792 HINGE-DOOR X X X
5 623166 PANEL RETAINER-UPPER (1 PER DOOR) X X X
6 622831 BIN-DOOR SHELF (1 PER DOOR) X X X
7 618746 HINGE BUSHING-MIDDLE X X X
