Hardware description
Solder bridge Default Function
SB28 Open Short to reset the interface MCU.
SB29 Closed Cut to disable power for interface MCU.
SB30 Closed Cut to isolate P0.17 from I/O expander interrupt line.
SB31 Closed
Cut and connect one side to VDD to erase interface MCU flash.
1
SB32 Open
Short to supply power through the Debug OUT connector.
2
SB33 Open Short to connect 5 V from connectors to VBUS.
SB34 Closed Cut to disconnect the 5 V to connectors.
SB35 Closed Cut to disconnect VDD on connectors.
SB36 Closed Cut to disconnect IF Boot/Reset button from the IMCU.
SB41 Closed No function on current BOM.
SB42 Open Short to connect IF Boot/Reset button to RESET pin on the Arduino
interface.
SB43 Open Short to connect the RESET pin on the Arduino interface to the
nRF52832 P0.21/RESET pin.
SB44 Open No function on current BOM.
SB45 Open No function on current BOM.
Table 8: Solder bridge configuration for nRF52 DK (v1.0.0 and higher)
CAUTION:
1
This function is not recommended because it bricks your DK unless you have the tools
needed to reprogram the interface MCU.
Note:
2
While this is shorted, you cannot program and debug the on-board device.
The following table is a complete overview of the test points on the nRF52 DK.
