NordicTrack A.C.T. Elite User Manual

11
7
8
7. Align the plastic post inside the Right Handrail
Cover (7) with the indicated hole in the Right
Shield Cover (76).
Press the Right Handrail Cover (7) onto the
Right Shield Cover (76) and onto the Right Outer
and Inner Shields (17, 19).
Attach the Right Handrail Cover (7) with an M4 x
16mm Screw (67).
Attach the Left Handrail Cover (6) in the same
way.
8. Attach the Rear Upright Cover (21) to the Upright
(2) with five M4 x 16mm Screws (67); do not
tighten the Screws yet.
2
67
67
21
67
17
7
6
19
76
Hole
Post

NordicTrack A.C.T. Elite Specifications

General

Brand	NordicTrack
Model	A.C.T. Elite
Category	Elliptical Trainer
Language	English
