12
6. Identify the left handrail assembly (A). Attach
the left handrail assembly to the Left Upright
(89) with two 5/16" x 2 1/2" Screws (28) and two
5/16" Star Washers (11); do not fully tighten
the Screws yet.
Then, remove and discard the indicated
screw (B).
6
89
A
B
28
11
7. Insert the Upright Wire (81) into the bottom of
the right handrail assembly (C) and out of the
front as shown.
Attach the right handrail assembly (C) to the
Right Upright (90) with two 5/16" x 2 1/2" Screws
(28) and two 5/16" Star Washers (11). Make
sure not to pinch the Upright Wire (81); do
not fully tighten the Screws yet.
Then, remove and discard the indicated
screw (B).
28
11
C
90
81
7
B
To Next Page
