17
18. Firmly tighten the six 3/8" x 4" Screws (7) (only
one side is shown).
Then, press the Left Base Cover (82) and the
Right Base Cover (83) onto the Base (94).
17
18
83
82
73
94
7
17. Attach the Tray (73) to the Upright Crossbar
(41) with four #8 x 3/4" Screws (2); start all four
Screws, and then tighten them.
2
41
2
