NordicTrack GX 4.5 PRO User Manual

12
15
4
8
34
15. Attach the Accessory Tray (8) to the Upright (4)
with two M4 x 18mm Truss Screws (34).
19
D
21
C
16. Identify the Right Pedal (21). Using an adjust-
able wrench, firmly tighten the Right Pedal
clockwise into the Right Crank Arm (19).
Firmly tighten the Left Pedal (not shown)
counterclockwise into the Left Crank Arm
(not shown). IMPORTANT: You must turn the
Left Pedal counterclockwise to attach it.
To adjust the pedal straps (C), see HOW TO
ADJUST THE PEDAL STRAPS on page 14.
16
