NordicTrack S15i User Manual

8
2
3
105
105
2. Attach the Front Stabilizer (3) to the Base (2)
with four M10 x 20mm Screws (105); do not
fully tighten the Screws yet.
See the inset drawing. Finish attaching
the Front Stabilizer (3) with two additional
M10 x 20mm Screws (105).
Then, fully tighten all six M10 x 20mm
Screws (105).
See the inset drawing. Press the right Leg
Cover (64) downward and attach it to the Base
(2) with an M4 x 10mm Machine Screw (12).
Attach the left Leg Cover (not shown) in the
same way.
105
12
64
2
105
2
3

NordicTrack S15i Specifications

General

Display	14-inch HD Touchscreen
Resistance Levels	22 Digital Resistance Levels
Incline	20% Incline
Flywheel	Inertia-enhanced Flywheel
Weight Capacity	350 lbs
Connectivity	Bluetooth Headphone Connectivity
Decline	10% Decline
iFit Compatibility	iFit Enabled
Warranty	10-Year Frame, 2-Year Parts, 1-Year Labor Warranty
