NordicTrack S15i User Manual

9
3
4
105
105
3. Attach the Rear Stabilizer (4) to the Base (2)
with four M10 x 20mm Screws (105); do not
fully tighten the Screws yet.
See the inset drawing. Finish attaching
the Rear Stabilizer (4) with two additional
M10 x 20mm Screws (105).
Then, fully tighten all six M10 x 20mm
Screws (105).
2
105
4
105
4
4. See the inset drawing. Orient the Handlebar
Post (7) so that the lower slot (A) is on the side
shown.
Next, loosen the indicated Post Knob (100) and
insert the Handlebar Post (7) into the Frame
(1) until the lower end of the Handlebar Post is
below the Frame. Then, tighten the Post Knob.
Then, insert the end of the Lower Wire (122) into
the Frame (1) and the Handlebar Post (7) and
pull it out of the upper slot (B) in the Handlebar
Post as shown by the dashed line at the right.
100
100
122
7
A
B
1
7
1

NordicTrack S15i Specifications

General

Display	14-inch HD Touchscreen
Resistance Levels	22 Digital Resistance Levels
Incline	20% Incline
Flywheel	Inertia-enhanced Flywheel
Weight Capacity	350 lbs
Connectivity	Bluetooth Headphone Connectivity
Decline	10% Decline
iFit Compatibility	iFit Enabled
Warranty	10-Year Frame, 2-Year Parts, 1-Year Labor Warranty
