Nordson Asymtek
Mini and micro dispensing solutions for fluids and pastes
page 16 off 20
5. Service and -intervals
Due to the many different materials and applications, it is very difficult to suggest an accurate
plan for service. Factors which influence the intervals:
1. Operation and environmental temperature
2. Viscosity, abrasiveness, aggressiveness of the material
3. Pump speed
4. Worker and service personnel
5. Cleaner and cleaning fluids
We suggest using ASYMTEK pumps according the physical and possible properties of the
design. Clean always with thoroughness. Furthermore, we suggest to exchange the wearing
and tearing parts (see point 7) each 1/2 year. Wet lubricants without particles may need
exchange only after 12 months with 8/5 operation mode.
Elastomer parts with a shelf live of more then 1 year, should not be used any more.
Elastomers age over time and loose their properties.
Do only use original spare parts.
Housing parts can be cleaned with a soft tissue and an inert cleaning fluid.
Explicit compliance for the pumped material:
Depending on the application, the maximum temperature may never succeed 120°C. With
the use of aggressive products, please do always contact your distributor and product
supplier to get approval before operation and or commissioning.
Make sure, that the local legislation has been incorporated all safety relevant demands are
being kept.
Changes done by the user result in loss of warranty. All damage claims upon will be ignored.
All safety relevant technical issues lose the ASYMTEK warranty support.
This sign shows a safety relevant message. Make sure all
operator personnel and safety people take note or have been
made aware.
