Nordson ASYMTEK User Manual

Nordson Asymtek
Mini and micro dispensing solutions for fluids and pastes
page 15 off 20
The rotor-drive-assembly is made of 1 piece only and cannot be
dismantled. Please only use inert lubricants for assembly. Generally, they are
not needed and can leave unwished residue. Never use silicone based
lubricants for automotive applications because they are forbidden.
4.3 Leakage
The pumps are equipped with a leakage detection in the front of the pump housing (9).
Whenever product comes out of the bore, you immediately have to stop the motor and
dismantle the unit. See 4.2
picture shows example
Seal

Nordson ASYMTEK Specifications

General

Fluid Types	Adhesives, underfills
Dispensing Technologies	Jet, needle
Work Area	Varies by model
Vision System	High-resolution cameras for alignment and inspection
Applications	Underfill, encapsulation, solder paste dispensing, adhesive dispensing
Material Compatibility	Compatible with a wide range of materials, including those with high viscosity or abrasive properties
