Nordson DuraBlue D10L Customer Product Manual

Parts
7-11
Part 1032059B
E 2003 Nordson Corporation
Manual 41-DURABLUE-MA-02
Item Part Description Quantity Note
— 1031207 Service kit, manifold, 2-port, 600 psi, unfiltered —
— 1031208 Service kit, manifold, 4-port, 1100 psi, filtered —
1 - - - - - -
S Manifold assembly
1
2 - - - - - -
S O-ring, Viton, 0.750 x 0.938 x 0.094 in.
1
3 - - - - - -
S O-ring, Viton, 1.188 x 1.388 x 0.094 in.
1
4 - - - - - -
S Screw, hex, cap, M8 x 90, 304 stainless-steel
2
5 - - - - - -
S Washer, flat, narrow, M8
2
6 - - - - - -
S Connector, with O-ring, hose,
9
/
16
-18
1 or 2 A
6 - - - - - -
S Connector, 90 degree,
9
/
16
-18 x
9
/
16
-18
1 B
NS - - - - - -
S Grease, high-temperature, 0.50 oz
1
— 1031221 Service kit, valve, pressure control, 600 psi —
7 - - - - - -
S Valve, PCV, 600 psi
1
— 1031222 Service kit, valve, pressure control, 1100 psi —
7 - - - - - -
S Valve, PCV, 1100 psi
1
8 1021941 Filter, with O-ring, 50-mesh 1
1028305 Filter, with O-ring, 100-mesh 1
1034720 Filter, with O-ring, 150-mesh 1
NS - - - - - -
S O-ring, Viton,
3
/
4
in. tube
1
NS - - - - - -
S Lubricant, Parker, high-temperature
1
NOTE A: The 2-port manifold service kits include one hose connector. The 4-port manifold service kit includes
two hose connectors.
B: This hose connector is included only in the 4-port manifold service kit.
NS: Not Shown
