Nordyne Q5RF-KA Series User Manual

13
FIGURES & TABLES
MODEL NUMBER LENGTH (L) WIDTH (W) HEIGHT (H) A B
X24KA 49 35 30.2 40.15 7.61
X36KA 49 35 30.2 35.02 2.48
X48KA 49 35 38.2 35.02 2.48
X60KA 63 35 38.2 35.02 2.48
Table 3. Physical Data
A
3”
Opening for
12" Diameter
Supply Duct
9.15
17.50
9.0
Opening for
14" Diameter
Return Duct
10.15
5.5
B
1”
3.15
RearView
L
W
18.01
Electric Heater Power Supply
Power Supply
Low Voltage Supply
Control
Access
Panel
Blower Access Panel
H
17.86
15.36
10.10
3/4" NPT
Drain Connection
1"
12.13
1.38
3.2
3.2 5.29
Figure 8. Unit Dimensions
TopView
SideView

Nordyne Q5RF-KA Series Specifications

General

Brand	Nordyne
Model	Q5RF-KA Series
Category	Heat Pump
Language	English
