Nordyne Q5RF-KA Series User Manual

14
Refrigerant Charging Charts - Cooling Mode
Figure 10. Charging Chart for 3 Ton Units
200
225
250
275
300
325
350
375
400
425
450
475
500
525
550
575
600
70 75 80 85 90 95 100105 110115 120125 130135 140
LIQUID PRESSURE (PSIG)
LIQUID TEMPERATURE (F)
X36KA CHARGING CHART
Remove refrigerant when above curve
Add refrigerant w hen below curve
Figure 9. Charging Chart for 2 Ton Units
200
225
250
275
300
325
350
375
400
425
450
475
500
525
550
575
600
70 75 80 85 90 95 100105 110115 120125 130135 140
LIQUID PRESSURE (PSIG)
LIQUID TEMPERATURE (F)
Remove refrigerant when above curve
Add refrigerant w hen below curve
X24KA CHARGING CHART
