Operator’s manual
Optima 51 / M51 / M56 / M57T / 60T
34
Dynapôle Ludres/Fléville, 166 rue Ampère/BP 60093 - 54714 LUDRES - FRANCE - Tél.+33 (0)3 83 25 69 60 - Fax. +33 (0)3 83 26 12 85
Step 5:
Check the stability of the tractor and machine combination. To do this, extend the arm of the machine
to maximum horizontal reach with the tool held at 1 metre above the ground (gure 2.17).
maximum additional
weight recommended
by the manufacturer
gure 2.17
1m
The balance is correct if the tractor does not lean over on the left side, it is important that the right rear
wheel retains weight on the ground (left hand build machines). (gure 2.17)
The distribution of weight should be approximately 15% of the total weight of the tractor and machine
remaining on the right rear wheel. (Left hand build machines).
Operation and maintenance
