˙Norman
®
Hub Button Function
FunctionNO. Description
˙Press once: Join network.
˙Press for 3 seconds to initiate User Setting Mode: (lasts 5 seconds)
1. Press once: Search shutters.
2. Press twice: Station Mode switch to AP Mode.
˙Press for 20 seconds to Factory Reset Norman
®
Hub.
Hub button1
FunctionNO. Description
1. Hold Norman
®
Hub button for 3 seconds to initiate User Setting mode.
The LED will turn blue.
2. Press once within 5 seconds right after step 1.
3. LED will blink in blue and white as it searches shutter status.
4. Once it finishes searching, LED will light on in white to indicate normal status.
Manual Search1
Station Mode means Norman
®
Hub is connected to your home router.
AP Mode means Norman
®
Hub is working as a standalone Access Point.
1. Hold Hub button for 3 seconds to initiate User Setting Mode. The LED will turn blue.
2. Press twice within 5 seconds.
3. Hub will switch to AP Mode from Station Mode.
4. Once AP Mode is working successfully, the WiFi SSID “NORMANHUB_OOOOOO” will
appear on your smart phone.
Station Mode to AP Mode2
1. Hold Norman
®
Hub button for 20 seconds.
2. Hub will reboot and start Factory Reset.
3. Once booted, LED will light in white.
Factory Reset
[Note: User data saved on the
Hub will be deleted.]
3
1. By default Norman
®
Hub will be in AP Mode in following situations:
˙Not connecting to Home router Wi-Fi
˙Not connecting to Ethernet cable
2. Once AP Mode is working successfully, the “NORMANHUB_OOOOOO” will appear
on your smart phone.
3. The default password is "norman1974".
AP Mode 4
1. Connect Norman
®
Hub to Home AP by Ethernet cable.
2. With Ethernet connection, Hub will work as Station Mode. The SSID will not be detected.
Connecting to Home AP via
Ethernet cable
5
1. Unplug and re-plug power cable.
2. Orange LED will blink as it boots up.
Reboot6
Page 06/09
Repeater Installation
˙Plug Repeater to Power Adapter.
˙Repeater deployment guide:
1. Each room needs a Repeater installed.
2. If the signal transmission path might be shielded by wall or something, then need
Repeater installed.
3. The distance between Hub and Repeater, or Repeater to Repeaters better less than 10 meters.
4. If the signal needs to pass through different floors, the repeater should be installed
around the stairs as well.
4、Troubleshooting
IssuesNO. Troubleshooting
DO NOT manually operate it. Please follow the steps
1. Wait 5 seconds and check if they release automatically?
2. Do the normal operation by Remote and check for normal operation. Check whether louvers are
released after movement stops?
3. Press PerfectTilt
™
Motor Module button once to initiate pairing mode and see if louvers move to a
horizontal position. Check whether louvers are released after movement stops?
4. Power off Motor Module press Module button for 3 seconds and then power it on (Pressing Motor
Module button for 3 seconds, check whether shutters calibration normally and move to horizontal
position. Check whether louvers are released after movement stops?
5. Do PerfectTilt
™
Motor Module Hardware Reset (Hold Motor Module Button for 10 seconds)and
power-on PerfectTilt
™
Motor Module, check whether shutters calibration normally and move to
horizontal position? Check whether louvers are released after movement stops?
6. Check if PerfectTilt
™
Motor Module is running out of power (LED in red or off). If PerfectTilt
™
Motor
Module is running out of power, please charge it by power bank or power supply via USB cable. (
Normally it takes around 10 hours to recharge.)
Louvers are stuck.1
2
1. Ensure Remote is not running out of power?(Lights up normally without sudden extinction)
2. Check PerfectTilt
™
motor module to receive the message light:
˙Green light : Indicates that the operation is normal.
˙Red light : Indicates low battery, or abnormal status.
˙No light : Please try rebooting to confirm that the module is exhausted.
3. If the motor module is exhausted, please charge it with a USB power source.
4. Ensure distance between Remote and PerfectTilt
™
Motor Module is or been blocked?
5. Check Repeater LED blinking status for Remote signal transmission(while Repeater is properly installed).
Ensure Repeater’s LED light blinks while operating the remote control?
6. Ensure PerfectTilt
™
Motor Module with Remote pairing is correct?
7. Power off PerfectTilt
™
Motor Module (press Module button for 3 seconds) and then power it on (press Module
button for 3 seconds).Check whether shutters calibrates normally and move to horizontal position? And check
whether shutters can be controlled by remote/App?
No reaction
upon operation
