Norsup P31V/32 - Page 9

2. SPECIFICATION
2.1 Performance data of Swimming Pool Heat Pump Unit
*** REFRIGERANT: R32
UNIT
P35V/32
Part nr.
7026973
Heating capacity
(A27/W26)
kW
7.1-35.0
Btu/h
24140-119000
COP
11.4-5.1
Heating capacity
(A15/W26)
kW
6.4-27.5
Btu/h
21760-93500
COP
6.5-4.1
Heating power input
kW
0.64-8.6
Power Supply
220-240V /50Hz
Compressor Quantity
1
Compressor
rotary
Fan Number
1
Noise
dB(A)
53-59
Water Connection
mm
50
Water Flow Volume
m3/h
14.6
Water Pressure Drop(max)
kPa
23
Unit Net Dimensions(L/W/H)
mm
See the drawing of the units
Unit Ship Dimensions(L/W/H)
mm
See package lable
Net Weight
kg
see nameplate
Shipping Weight
kg
see package label
Heating: Outdoor air temp: 27℃/24.3℃, Inlet water temp:26℃
Outdoor air temp: 15℃/12℃ , Inlet water temp:26℃
Operating range:
Ambient temperature: -15 43℃
Water temperature: 9-40℃
