Page #52 background imageLoading...
Page #52 background image
52
Figure 48. *SL & *SM Component Locations
Finish
Flange
Blower
Assembly
Blower Door Switch
(behind
blower panel)
Burner
Assembly
Flame
Sensor
Gas Manifold
Gas Valve
Igniter
Inducer Assemb
ly
Pressure Switch
Vent Limit Switch
Control Board
Main Air Limit Switch
Transformer
Roll-Out
Switch
DOWNFLOW FURNACE (*SL SERIES)
Burner
Assembly
Flame Sensor
Roll-Out
Switch
Finish Flange
Blower Assembly
(behind
blower panel)
Blower Door Switch
(behind blower panel)
Gas
Manifold
Gas Valve
Igniter
Inducer Assembly
Inducer Limit Switch
Fur
nace Control Board
Pressure Switch
Transformer
DOWNFLOW FURNACE
