Nortel DMS-100 Series Replacement Procedures

1-796 XPM card replacement procedures
297-8021-547 Standard 14.02 May 2001
NT6X19
in an RLCM
(continued)
Summary of replacing an NT6X19 card in an RLCM
This flowchart summarizes the
procedure.
Use the instructions in the
procedure that follows this
flowchart to perform the
procedure.
At LNS;LTP level,
post the line card
Is the line
status ManB?
Busy the line card
Replace the line
card
Test the line card
Return the line to
service
End of procedure
Did test pass?
Did return to
service pass?
Obtain assistance
from maintenance
support group
Obtain assistance
from maintenance
support group
Y
N
Y
N
N
Y
