Maintenance Instructions
66
4.12 Fuel Filter Maintenance
4.13 Engine Oil Filter Maintenance
The engine oil filter (A) is located under the bottom
center on the left side of the engine. It should be replaced
after every 200 working hours. When replacing the oil
filter also change the engine oil. For detailed
maintenance procedures, refer to the engine
manufacturer’s Operation Manual.
Figure 4-15 Engine Oil Filter Maintenance
4.14 Hydraulic Oil Filter Maintenance
The hydraulic oil filter (A) is located under the starter
motor on the lower right side of the engine. The cleaning
method is as follows. Place a drip pan under the filter,
then loosen and remove the end cover. Remove the
hydraulic oil filter element and use solvent to clean it,
then use compressed air to blow it dry. Replace the filter
element when cleaning it becomes difficult or it is
damaged.
A
Figure 4-16 Hydraulic Oil Filter Maintenance
The diesel fuel filter is located on the top left of the
engine. Open the tractor hood to access it. Never wash
the paper filter element of the filter. The fuel filter
element should be replaced after every 200 working
hours. For detailed maintenance procedures, refer to the
engine manufacturer’s Operation Manual.
Figure 4-14 Fuel Filter Maintenance
