Nortrac 35XT - Main Bolts, Screws and Nuts Tightening Torque

Appendices
82
10.2 Main Bolts, Screws and Nuts Tightening Torque
Table 10-2 Main Bolts, Screws, and Nuts Tightening Torque Table
Name and Assembly Position
Thread
Specification
Tightening
Torque [N·m]
Tightening
Torque [LB FT]
The bolt and nut connecting the engine and the
clutch housing.
M10 41~51 30~37
The bolt connecting the clutch housing and the
rear axle casing.
M14X1.5 123~154 90~113
The bolt securing the bearing block of the primary
shaft and the secondary shaft.
M10 41~51 30~37
The bolt securing the interlocking wedge. M10 50~70 36~51
The bolt connecting the slave drive spiral bevel
gear.
M10X1.25 45~55 33~40
The bolts connecting the drive shaft shell and the
rear axle housing.
M12×1.5 73~89 53~65
The bolt connecting the driving wheel hub and the
radial plate.
M18×1.5 397~457 293~337
The lock nut that locks the front shaft cross bar. M16X1.5 122~149 90~110
The bolt connecting the subassembly of the front
outer shaft and the front inner shaft.
M14 122~149 90~110
The bolt connecting the front driving wheel, the
front wheel hub and the radial plate.
M14×1.5 178~218 131~160
The bolt connecting the front axle and the bracket. M16 182~222 134~164
The bolt connecting the front bracket and the
battery tray.
M12 73~89 53~65
The bolt connecting the bracket and the engine. M12 73~89 53~65
The bolt connecting the bracket and the engine. M14X1.5 126~154 93~114
The bolt connecting the lifter shell and the rear
axle housing.
M10 41~51 30~37
The bolt connecting the steering gear and the
clutch housing.
M14 122~149 90~110
The coupling bolt for the limited rod support. M14 122~149 90~110
