10.4 Seals on the Tractor Chassis:
Table 10-4 Detailed List of Tractor Chassis Seals
Component Specification Assembly Position Qty.
B35×55×8 Front of the Primary Shaft 2
FB35×55×8
Inside of the Bearing Cover
of the Power Take Off Shaft
2
B50×72×8 Outside of the Drive Shaft 6
GB/T 9877.1
Rotary Shaft Lip
Seal
B55×75×8 Inside of the Drive Shaft 4
JB/T2600
Oil Seal
PD50×80×12
Driving Gear Shaft of the
Final Drive
2
11.8×1.8G
Shifting Fork Shaft of the
Power Take Off
1
15×2.65G
Shifting Fork Shaft of the
Differential Lock
1
22.4×2.65G Reverse Shaft 1
28×3.55G
Driving Gear Shaft of the
Final Drive
2
67×3.55G
Front Bearing Block of the
Secondary Shaft
1
103×3.55G
Bearing Block of the Rear
Axle
2
Transmission
Box
GB/T3452.1
O-Ring
112×3.55G Drive Shaft Sleeve 2
Brake GB/T3,452.1
O-Ring
15×2.65G Brake Camshaft 2
Vertical Axle Oil Seal
38×74×11.5
Lower End of the Steering
Knuckle
2
Front Shaft
Non-Standard
(Shown in the
Drawing)
Half Axle Oil Seal
38×74×11.5
Front Wheel Hub 2
